Operating instruction for SICON.PLUG AI CobotPump ECBPi

Note
The product information is originally written in German. Please retain a copy of this document for future reference. Subject to technical modifications without prior notice. No liability is assumed for printing or any other errors.

Published by
© GPS GmbH, 02/24
This document is protected by copyright. GPS GmbH retains the rights established therein. Reproduction of the contents, whether in full or in part, is only permissible within the boundaries of the legal provisions of copyright law. Any alterations to or abbreviations of the document are strictly prohibited without explicit written consent from GPS GmbH.

GPS GmbH · Nobelstr. 15 · 70569 Stuttgart, Germany · T: +49 711 6870 31 30
info@gps-stuttgart.de

Important Information

1.1 The technical documentation is a part of the product.

1. Keep the technical documentation near the product for easy access and follow the instructions carefully.

2. Share the technical documentation with subsequent users.

Attention:

• Not adhering to the instructions mentioned in the operating manual may result in life-threatening injuries!

• GPS bears no liability for damages or malfunctions resulting from non-compliance with these instructions.

If you have any queries about the technical documentation, please contact us at: info@gps-stuttgart.de

1.2 Note on Using these Operating Instructions

This operating manual includes important details and guidance for various stages of the product's operation:

1. Transport, storage, start of operations and decommissioning.

2. Safe operation, necessary maintenance, and troubleshooting.

The manual describes the product as provided by Schmalz at the time of delivery. Images are for reference only and may vary based on specific product configurations.

Fundamental Safety Instructions

1. Intended Use

The SICON.PLUG AI CobotPump ECBPi turns your device with a UART interface into a smart device. Parameters can be changed and data can be transported to your company network via the integrated WLAN.

2. Non-Intended Use

GPS GmbH bears no liability for direct or indirect losses or damages occurs from the use of the product. This disclaimer applies specifically to any use of the product that deviates from its intended purpose or is not described in this documentation.

3. Personnel Qualifications

Unqualified individuals may overlook hazards, which may lead to increased risks!

1. Electrical work and installations may only be handled by qualified electricians.

2. Assembly and adjustment work may only be performed by qualified individuals.

These operating instructions are intended for skilled technicians who are expertise in product handling and installation.

4. Warnings in This Document

Warnings alert about potential hazards during product handling. The signal word signifies the level of danger.

5. Environmental and Operating Conditions

The SICON.PLUG AI CobotPump ECBPi must be operated only under the following conditions:

• Temperature range from 0 °C to + 50 °C.

• Maximum relative humidity 90%, non-condensing.

Avoid list: The product must not be operated under the following conditions:

• Operating the product in an explosive environment may lead to an explosion.

In case of doubt, please consult GPS before operation.

6. Technical Condition:

Operating the product while in a defective state may impaired the safety and functionality.

• The product must be operated when in perfect technical condition, i.e., its original state

• Maintenance plan must be followed.

• If there are changes in the operating behaviour, immediately examine the device for faults and address them accordingly.

If the fault cannot be immediately addressed, switch off the device and label it as defective.

• Any alterations or modifications which are unauthorized, are prohibited.

• Do not make any modifications to the software.

7. Operator Responsibilities Regarding Country-Specific Regulations:

Adhere to country-specific regulations concerning accident prevention, safety testing, and environmental protection.

Product safety note

Please read the following information carefully. The manufacturer accepts no liability due to improper use of the product.

• Keep the product out of the reach of children.

• Please avoid cleaning the product with excessive use of water.

• Please protect the open ports of the product from water, dust and dirt entrance by appropriate mounting or dust caps.

• Protect the vacuum connections of the product from over pressure.

• The operating voltage must not exceed the maximum values specified in these operating instructions.

• Observe the maximum values of the potential-free contacts, if you use them.

Introduction

Congratulations, with the purchase of the SICON.PLUG AI CobotPump ECBPi. It turns your device with a UART interface into a smart device. Parameters can be changed and data can be transported to your company network via the integrated WLAN.

Collisions and vibrations are reliably detected via the built-in acceleration sensor and reported to the maintenance engineer or service personnel.

The built-in replay function makes your process transparent and enables you to visualize the last 30s of the process again.

Prepared visualizations and events help with process optimization and provide information about future maintenance and existing system errors.

Within minutes, your SICON.PLUG ANALYTICS PVS is up and running and ready to provide you with real added value.

Advantages of your SICON.PLUG AI CobotPump ECBPi

Connection

• No additional power supply required as the SICON.PLUG AI CobotPump ECBPi can be supplied directly with 3,3V DC +/- 10% industrial standard.

• Network connection via 10 MBIT/s Ethernet or WLAN 2.4 GHZ with antenna according to IEEE802.11b/g/n possible.

• High-speed transmission of measured data through modern scalable protocols.

• Integrated acceleration Sensor - 3-axis acceleration and rotation rate sensor +/- 2g

Industry 4.0 Ready

• Relaxed secure global access to your data by transferring it to the cloud.

• Intelligent user management ensures that each department sees the data that is important to them.

• Simple commissioning via an app.

• Easy configuration of parameters via an internet browser.

Analytics

• Direct evaluation of your measured data and display via status LEDs using an innovative colour concept.

• Predictive maintenance through sophisticated algorithms.

• Messages and notes provide information on where there is still potential for improvement in your vacuum process.

• The revolutionary replay function freezes your process. This allows errors and optimization attempts on the process to be analysed and tested in detail.

• The built-in collision detection generates an error message as soon as, for example, an industrial truck collides with your vacuum system or a rough use has damaged it. This allows you to detect defective or critical machine conditions before they occur.

Structure of your SICON.PLUG AI CobotPump ECBPi

1.1 Front panel controls

Important functions

Coming soon….

Tips and help

1.18 Technical data

1.19 CE conformity and disposal of old equipment

The manufacturer GPS Stuttgart GmbH confirms that the SICON.PLUG AI CobotPump ECBPi product described in these operating instructions complies with the following relevant EC directives:

The following harmonized standards have been applied:

EN 61000-4-2: 2009   Electromagnetic compatibility - Static electricity discharge

EN 61000-4-3: 2006   Electromagnetic compatibility - High frequency electromagnetic fields

Please dispose of the product properly after replacement or decommissioning in accordance with the country-specific guidelines and legal obligations for waste prevention.

Next steps

• Setting Up via the SICON.ToolBox App.

How to's 👉 Quick start installation video
